Mori ZY-M100-24G Micro Motion Sensor

• Version V1.2

Product Function

• Fretting detection

It can detect small movements such as hand lifting, hand flicking, hand turning, etc.

• Presence detection

It can detect the human body standing still, squatting still, sitting still and other static states.

• Motion detectionIt can detect walking, trotting, fast running, circling, jumping and other movements.

• Distance measurement

The target distance measurement function can accurately filter targets outside the area.

• Illuminance detection

Detectable illuminance value.

• Log query

It can query the records of human existence and illumination change.

• Adjustable parameters

Various parameters such as detection distance can be set through app.

• Fault detection

Equipment fault information can be self-checked through app.

o Application Area

• The ZY-M100 micro motion sensor can be widely used in lighting, security, home appliances,

hotels, garages, buildings, etc.

o Product Information

• Model: ZY-M100-2

• Input voltage: AC 80-250 V

• Detection distance: 0-8 m

• Detection angle: 120° × 120°

• Hole size: 52 mm-56 mm

• Version: Ceiling version
